Stretch Film Slitting Machine

Stretch Film Rewinder Slitter With Width 1200mm

Stretch Film Rewinder Slitter With Width 1200mm

PPD-SFSR1200

Stretch film rewinder slitter with width 1200mm is our latest customized model for rewinding slitting of stretch film rolls.
It is a versatile machine that offers both rewinding and slitting capabilities. This means that it can be used to produce multiple rolls of stretch film with customized sizes. The machine operates on two stations, making it possible to produce two different sizes simultaneously. This feature saves time and increases productivity.
It is also user-friendly, with easy-to-use controls that can be configured to meet the specific needs of the operator,which ensures that the machine can be operated by anyone.


Features:
1.With a maximum width of 1200mm and a speed of up to 600m/min.
2. It is a versatile machine that offers both rewinding and slitting capabilities

Technical Data:

Model:PPD-SFSR1200

Jumbo roll width:Max1200mm

Jumbo roll OD:max500mm

Jumbo roll ID:3inch(76mm)

Finished roll width:30 to 1200mm

Finished roll ID:38/50/76mm(1.5/2/3inch)

Finished roll OD:max180mm

Speed:max 600m/min

Power:1.7kw

Voltage:220/380/415V option

Air supply:0.2Mpa
