Automatic aluminum foil roll rewinder with automatic sticker is design for rewinding of aluminium foil with auto label sticker,which is easy to use the foil roll.
Machine is 4 shaft automatic exchange rapid rewinding of aluminium foil from longer jumbo roll into shorter small roll.
The layout and operation make it user friendly and ideal for volume production.

Features:
1. Machine structure is simple, easy operation, easy maintenance.
2. Easy adjusting to fit different length of paper core.
3. Auto exchanging and keep it continous running.
4. Easy to set the different length in touch screen directly, length precision reach to 0.01mm.
5. Low noisy, low power consumption, uniform winding.

Main Data:
Name:Automatic Aluminum Foil Roll Rewinder With Automatic Sticker
Model:PPD-AAFL450
Width of material: 300-450mm
Thickness of material: 7-50 micro
Rewinding speed:2.5m/s
Maximal diameter of Jumbo roll: 600mm
Rewinding length: 2.5-100m/roll
ID for the Jumbo roll: 3”
ID for the rewinded paper core: 25/30/38/40mm option
Magnetic powder braker:25NM
Magnetic powder clutch:12NM
Total power:4Kw
NOTE:Different sizes can be customized.
