Coreless kraft paper rewinder is a multi-functional model,can rewind of kraft paper,book cover,wallpaper,gift paper,nonwoven fabric,car window film,PVC film,OPP film etc,the final product is without paper core.
Machine adopts private server motor and PLC control system to keep acceleration and deceleration smooth and stable.
Features:
1.Automatic meter counting, automatically stop and cut off when the number of meters is reached.
2.The rewinding adopts a single air shaft structure, which is convenient for loading and unloading operations.
Main Data:
Name:Coreless Kraft Paper Rewinder
Model:PPD-CFPR800
Unwind roll width:800mm
Unwind roll diamter:max1000mm
Unwind roll inner diameter：76mm
Rewind roll width:max800mm
Rewind roll inner diameter:25mm or as customized size
Rewind roll outer diameter:max250mm
Speed:max200m/min
Power supply:4.5kw
Voltage: 380V, 50hz
NOTE:Different sizes can be customized.
