PE Food Wrap Paper Rewinder

Fully Auto Food Paper Rewinding Machine With Labeling Application

Fully Auto Food Paper Rewinding Machine With Labeling Application

PPD-FPRL450

Fully auto food paper rewinding machine with labeling application is used to rewind of food paper,like silicon paper,baking paper,PE coated paper,wax paper,glassin paper,bakery paper into small which with auto label sticker.
Machine adopts PLC to be control system from Simens of Germany, it can be done to feed paper core, pick-up, adhering and cutting rolls,automatically in production. It uses computer control to setup and measure the length of rolls.
Machine can rewind aluminium foil roll,kitchen foil roll,household foil rol,cooking foil too.

Features:
1.The control system is continous speed adjustable of food paper/foil rolls.
2.All drivers are automatic, less defect, safety, high efficiency and simple in operating.
3. Air shaft system fixed the raw material and keep the material tight and stable.
4.Frequency Control, the speed will show in the control panel

Main technical parameters:

Name:Fully Auto Food Paper Rewinding Machine With Labeling Application

Model:  PPD-FPRL450

Material thickness:0.0085mm-0.025mm

Max. unwinding Width :450mm

Max. unwinding Diameter:600mm

Mother core diameter:76mm/152mm option

Max.rewind width:450mm

Product core diameter:30mm/35mm(optioo)

Producing speed:2.5m/s

Length of product: 3m-150m

Motor power:4KW

Voltage :380V,3ph

Frequency:50HZ

NOTE:Different sizes can be customized.
