Automatic Stretch Film Rewinder

Fully Automatic Extended Core Stretch Wrap Film Rewinder

Fully Automatic Extended Core Stretch Wrap Film Rewinder

Fully automatic extend core stretch wrap film rewinder is specially designed for high speed rewind of PE stretch film jumbo roll into sub roll with extended core and standard core.
Machine is completed with PLC and manual control panel together with inverter control system,easy to operate and run the machine.
Beside rewidning of stretch film,pallet stretch wrap,industrial stretch
wrapping film,food stretch wrap film,it is also designed for
automatically food cling wrap film rewinding.

Features:
1. Paper core hopper,loading and changing paper core automatically
2. Heating wire cutting product roll automatically
3. One worker can operate two or three machines with conveyor at same time.
4.Conveyor belt and receiving table collect of finished product roll automatically.

Technical Data:

Name:Fully Automatic Extended Core Stretch Wrap Film Rewinder

Model:PPD-AECRW500

Material: PE Stretch film,PVC/PE cling film

Width of film roll: max500mm

Maximum guide roller width: 520mm

Inner diameter of unwind roll: 76mm

Sub roll width include extended core:300mm, 350mm,400mm,500mm or as customized size

Inner diameter of sub roll: 38mm/50mm/76mm

Outer diameter of rewind roll: max150mm

Speed : max1200m/min

Voltage: 220/380/415v,3ph

Power:4.37kw
