Semi auto 18kg stretch film rewinder is works with slitting and rewinding functions.
It can rewind the film from large diameter roll to several small diameter rolls.It also can split to several small width rolls.
The max weight of this model can do rewind the product roll max to 18kg.
By slitting and rewinding, the false-laid layer will be corrected, and defect of printing and pasting will be repaired. The film will become smoother and looked better.
Features:
1.Control is simple, easy to operate
2.High speed, Rewinder inverter, PLC control.
3.Rewinder speed motor control power 2.2 kW
Main Data：
Name:Semi Auto 18kg Stretch Film Rewinder
Model:PPD-18kg-SASR500
Width of mother roll:500mm
Mother roll diameter:400mm
Core size of mother roll:3inch
Width of finish roll:min50mm-max500mm
Core size of finish roll:1.5inch,2inch,3inch
Finish roll diameter:max250mm
Speed:600m/min
Voltage:220/380/415V,50hz/60hz
