New model 2 shaft pe stretch film slitter rewinder with touch screen is our latest model to slit and rewind of PE stretch film,Industrial stretch film,pallet stretch film,LLDPE film,HDPE film rolls etc.
It works with 2 exchange shaft to divide the large diameter film into several small rolls. It is convenient and flexible to adjust, low noise, frequency conversion speed regulation, and automatic rewinding counter.
Features：
1.Different width can be set 50-500mm option,max width to jumbo roll.
2.Meter setting adjustable,50/100/200m option
3.Different size of sub-roll core diameter can be choose,like 1.5inch,2inch,3inch
4.3inch size adopts air shaft rewind,1.5/2 inch size adopt plain shaft rewind.
5.Machine works with touch screen and PLC control for simple operation
Technical Data:
Name:New Model 2 Shaft PE Stretch Film Slitter Rewinder With Touch Screen
Model:PPD-SFSR500-TS
Jumbo roll width:500m
Jumbo roll weight: max50kg
Jumbo roll inner core diameter:3inch(76mm)
Rewind roll width:50 to 500mm
Rewind roll inner core diameter: 1.5/2/3inch(38/50/76mm)
Rewind roll outer core diameter:max180mm
Speed:max 650m/min
Power:1.7kw
Voltage:220/380/415V option
Air supply:0.2Mpa
NOTE：Any specifications can be customized.
